REPLACEMENT PARTS LIST
(
For Euro
p
e
)
The com
p
onents s
p
ecified for Model LCD1970NX
(
B
)
SYMBOL
For Europe
(NPG Part Number)
DESCRIPTION
*** ICS ***
U401 E1A12251 IC SMD MW1537BCM5
U402 EQ500117 CHIP FET P HAT1053M
U403 E1A12271 IC SMD GM5221-LF-BC
U405 EHA12331 IC SMD A290021TL-70
U406 EHA50051 IC SMD 24LC02B
U407 EHA50051 IC SMD 24LC02B
U408 EHA10081 IC SMD 24LC16B SO8
U409 EHA50011 IC MOS 74LVC14
U410 EHA10471 IC SMD MIC1815 RESET
*** TRANSISTORS ***
Q401 EN000211 CHIP TR NPN DTC114EUA
Q402 EN000211 CHIP TR NPN DTC114EUA
Q403 EN000211 CHIP TR NPN DTC114EUA
Q404 EN000211 CHIP TR NPN DTC114EUA
Q405 E2A00341 TR SMD MMBT3906-LF PNP SO
*** DIODES ***
D401 E4K00341 DI SMD SCS495D-LF
D402 E4K00351 DI SMD SCS217K-LF
D403 E4K00351 DI SMD SCS217K-LF
D404 E4K00351 DI SMD SCS217K-LF
D405 E4K00341 DI SMD SCS495D-LF
D406 E4K00351 DI SMD SCS217K-LF
D407 E4K00351 DI SMD SCS217K-LF
D408 E4K00351 DI SMD SCS217K-LF
D409 E4K00351 DI SMD SCS217K-LF
D410 E4K00351 DI SMD SCS217K-LF
D411 E4K00351 DI SMD SCS217K-LF
D412 E4K00351 DI SMD SCS217K-LF
D413 E4K00351 DI SMD SCS217K-LF
D414 EJ100231 DIODE 1N4001
D415 EJ100231 DIODE 1N4001
D801 EL500611 LED SMD JEC-3227UOGE
ZD401 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD402 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD403 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD404 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD405 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD406 EYD40562 CHIP DIODE ZENER UDZS5.6B
ZD407 EYD40562 CHIP DIODE ZENER UDZS5.6B
