NEC MultiSync LCD1970NX User Manual

SYMBOL
For Europe
(NPG Part Number)
DESCRIPTION
B434 80000991 BEAD WBR6H-3T-R7K-B5
B435 80000991 BEAD WBR6H-3T-R7K-B5
B436 HM017021 L BEAD SMD MCB1608S121G
B437 HM017021 L BEAD SMD MCB1608S121G
B439 HM017021 L BEAD SMD MCB1608S121G
B442 HM017021 L BEAD SMD MCB1608S121G
*** ELECTRICAL PARTS & MISCELLANEOUS PARTS ***
LCD
3A684091
(NMV Part Number)
TFT LM190E02-A4K5
P402 RA805152 CN MINI-D-SUB 15P SIDE
X401 E8100131 OSC X'TAL 49US 14.318MHZ
XD1002 RE010081 CABLE VIDEO GR DSUB-DSUB
XD1007 RG030031 PW CORD EU 2M R-PLUG GR
XD1010 R3201481 WIRE CC12P 1571#30L180
XD1011 R3201471 WIRE CC30P 1589#30L220
*** APPEARANCE PARTS ***
LABEL 15004101 LABEL RATING LCD1970NXH W
M-CONN 17002721 PAD,L194,LPL
XD1000 10107361 BACK L194RJ (N) WH
XD1001 10107611 BEZEL WH(N) BC L194RJ
XD1003 12001211 CHASSIS BASE 1970NXH,(LPL
XD1004 11700771 COVER UNIT WH L194RJ
XD1008 12302271 SHIELD 1970VH/NXH
XD1009 14900211 STAND UNIT L194R WH
*** PRINTED & PACKING MATERIALS ***
BAG-1 13700483 BAG LCD1960NX EPE
CARTON 13204921 CARTON BOX LCD1970NX B
MANUAL 15503533 MANUAL ASSY LCD1970NX B
WRNTY1 15802261 SHEET CAUTION PISA19 B
WRNTY2 15802161 SHEET SETUP LCD1970NX/V B
XD1005 13401781 FILLER B L194R,(A,B,C,)
XD1006 13401771 FILLER T L194R,(A,B,C,)
*** RESISTORS ***
F401 FM100000 CHIP 1/8W(T) 5% 0 H
F402 FM100000 CHIP 1/8W(T) 5% 0 H
R401 FM010103 CHIP RES 1/10W(T) 5% 10KO
R403 FM010103 CHIP RES 1/10W(T) 5% 10KO
R404 FM010103 CHIP RES 1/10W(T) 5% 10KO
R405 FM010103 CHIP RES 1/10W(T) 5% 10KO
R406 FM010000 CHIP RES 1/10W(T) 5% 0OHM
R407 FM010103 CHIP RES 1/10W(T) 5% 10KO
R408 FM010103 CHIP RES 1/10W(T) 5% 10KO
R409 F8012490 R SMD METAL 1/10W 249 F 0
R410 FM010103 CHIP RES 1/10W(T) 5% 10KO
R411 FM010103 CHIP RES 1/10W(T) 5% 10KO
8-4
