NEC MultiSync LCD4020 User Manual

English-25
English
CLOCK PHASE Adjusts the visual “noise” on the image. -
VGA, RGB/HV, DVD/HD inputs only
H RESOLUTION Adjusts the horizontal size of the image. -
DVI, VGA, RGB/HV inputs only
V RESOLUTION Adjusts the vertical size of the image. -
DVI, VGA, RGB/HV inputs only
ZOOM MODE Select the aspect ratio of the screen image. -
Does not work with TV input in the U.S.
BASE ZOOM CUSTOM
16:9 For input sources that have a 16:9 aspect ratio.
HDMI, DVD/HD, VIDEO, TV for Europe inputs only
14:9 For input sources that have a 14:9 aspect ratio.
HDMI, DVD/HD, VIDEO, TV for Europe inputs only
DYNAMIC Expands 4:3 picture to fill the screen. Some of the image is lost due to expansion.
HDMI, DVD/HD, VIDEO, TV for Europe inputs only
OFF Selecting “OFF” will display the image in a 1 by 1 pixel format. (If the input resolution is
higher than a 1360 x 768 resolution, the image will be scaled down to fit the screen.)
CUSTOM Displays an image as large as possible without changing the aspect ration.
ZOOM*
2
Maintains the aspect ratio while zooming. 1.00
H ZOOM*
2
Amount of horizontal zoom. Can be adjusted for each BASE ZOOM setting. 1.00
V ZOOM*
2
Amount of vertical zoom. Can be adjusted for each BASE ZOOM setting. 1.00
H POS*
2
Horizontal position. Can be adjusted for each BASE ZOOM setting. 0%
V POS*
2
Vertical position. Can be adjusted for each BASE ZOOM setting. 0%
INPUT RESOLUTION If there is a problem with signal detection, this function forces the monitor to display the AUTO
VGA, RGB/HV inputs only signal at the desired resolution. After selection, execute “AUTO SETUP” if required.
If no problem is detected, the only available option will be “AUTO”.
ADJUST RESET Resets the following settings within the ADJUST menu back to factory setting: -
AUTO ADJUST, H POSITION, V POSITION, CLOCK, CLOCK PHASE, H RESOLUTION,
V RESOLUTION, ZOOM MODE, INPUT RESOLUTION.
BALANCE CENTER
TREBLE 0
BASS 0
PIP AUDIO Selects source of PIP audio. MAIN AUDIO
LINE OUT Selecting “VARIABLE” will enable to control line out level with VOLUME button. FIX
AUDIO RESET Resets “AUDIO” options back to factory settings. -
OFF TIMER Sets the monitor to power off after a length of time. OFF
A time between 1 to 24 hours is available.
SCHEDULE SETTINGS Creates a working schedule for the monitor to use. -
SCHEDULE LIST List of schedules. -
DATE & TIME Sets the date, time, and daylight saving region. Date & time must be set in order for the -
“SCHEDULE” function to operate.
YEAR -
MONTH -
DAY -
TIME -
DAYLIGHT SAVING OFF
SCHEDULE RESET Resets the following settings within the SCHEDULE menu back to factory setting: -
OFF TIMER, SCHEDULE SETTINGS.
*: The product you purchased may not have this feature. *2: 16:9, 14:9, CUSTOM only
AUDIO*
SCHEDULE

NEC MultiSync LCD4020 Specifications

General

Pixel pitch	0.648 x 0.648 mm
Response time	8 ms
Display diagonal	40 \
Display brightness	500 cd/m²
Vertical scan range	50 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
Display number of colors	16.78 million colors
Aspect ratio	16:9
Display sRGB	Yes
Built-in camera	No
Headphone connectivity	3.5 mm
DVI-D ports quantity	1
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	600 x 200 mm
Power consumption (typical)	300 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE; TÜV GS; C-tick; FCC Class B; UL/C-UL or CSA; CCC; PSB; VCCI; RoHS
Cables included	AC, VGA

Weight and Dimensions

Depth	140 mm
Height	532 mm
Weight	29400 g
Depth (with stand)	330 mm
Width (with stand)	920 mm
Height (with stand)	567 mm
Weight (with stand)	31100 g
