NEC MultiSync LCD4020 - Specifications - LCD5220

English-41
English
Specifications - LCD5220
Product Specifications
LCD Module 52" /132.1 cm diagonal
Pixel Pitch: 0.6 mm
Resolution: 1920 x 1080 dots
Color: Over 16 million colors (depending on video card used)
Brightness: 700 cd/m
2
(Max.), 500 cd/m
2
(Typ.)
Contrast Ratio: 1700:1
Viewing Angle: 89° (typ) @ CR>10
Design View Distance: 1300 mm
Frequency Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical: 50.0 - 85.0 Hz
Pixel Clock 25.2 MHz - 162.0 MHz
Viewable Size 1192 x 688 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080 (60Hz)
VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080 (60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080 (60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI*
2
HDMI Connector Digital RGB HDMI
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
DVD/HD*
2
RCA (Y, Cb/Pb, Cr/Pr) Component Y : 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7 Vp-p/75 ohm
HDTV/DVD:1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO*
2
BNC Composite 1.0 Vp-p/75 ohm
RCA NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO*
2
Mini DIN 4 pin S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
RGB/HV BNC (R,G,B,H,V) Analog RGB 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Posi / Nega)
VIDEO*
2
BNC Composite 1.0 Vp-p with 75 ohm terminated
AUDIO*
2
AUDIO RCA (L/R) X2 Analog Audio Stereo L/R 0.5 Vrms
Input STEREO Mini Jack
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO STEREO Mini Jack Analog Audio Stereo L/R 0.5 Vrms
Output
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Control RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
TV*
2
For U.S For Europe
Antenna: F-connector Impedance 75 ohm F-connector Impedance 75 ohm
Channel Coverage: VHF: 2 - 13 ch VHF: E2 to E12/R1 to R12
UHF: 14 - 69 ch UHF: E21 to E69
CATV: 1 - 130 ch CATV: S1 to S41
ATSC (8VSB): 2 - 69 ch
64/256 QAM : 1 - 135 ch
Power Supply 4.7 - 1.9 A @ 100-240VAC, 50/60Hz
Operational Environment Temperature: 5 - 40°C
Humidity: 20 - 80% (without condensation)
Altitude: 3000 m
Storage Environment Temperature: -20 - 60°C
Humidity: 10 - 90% (without condensation)/ 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension Net: 1200 (W) x 696 (H) x 147.5 (D) mm (without stand)
Gross: 1481 (W) x 926 (H) x 334 (D) mm
Weight Net: 43.7 Kg (Without stand)
Gross: 52.0 Kg
VESA compatible arm mounting interface 2 x 200 mm x 2 x 200 mm (8 Holes)
Complied Regulatory and Guidelines UL60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/GOST-R
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI
Accessories User’s manual, Power Cord, Video Signal Cable, Remote Control, AA Battery x 2, Clamp x 3,
Screw x 9, CD-ROM, Thumbscrew for stand x 2, Cable cover
NOTE: Technical specifications are subject to change without notice. *1: Compressed image *2: The product you purchased may not have this feature.
