English−15
Installing a safety wire
WARNING: Please refer to “WARNING 9”.
CAUTION: Please refer to “CAUTION 7”.
NOTE: When installing, do not apply pressure to the LCD panel or excessive force to any part of the monitor by pushing or
leaning on it. This may cause the monitor to become distorted or damaged.
Handles for safety wire
(Fasten Force: 120 - 190 N•cm).
Safety wire for landscape position
Safety wire for portrait
position (ME651 only)
Mounting Location
WARNING: Please refer to “WARNING 8”.
NOTE: Allow for adequate ventilation or provide air conditioning around the monitor, so that heat can properly dissipate away
from the monitor and from the mounting equipment.
Orientation
• When using the monitor in the portrait position, it should be rotated counterclockwise so that the right side is moved to the
top and the left side is moved to the bottom. Improper ventilation may shorten the lifetime of the monitor.
Power Indicator
WARNING: Please refer to “WARNING 8”.
To Next Page
