CHECK HORIZONTAL
FREQUENCY C114 TO GND
CHECK
Q312 FREQUENCY
SYNCRONIZE
WITH H-SYNC
CHECK U301
NORMAL OPERATION
CHECK
Q101 G-S FREQUENCY
SYNCRONIZE
WITH H-SYNC
CHECK C114, R116
D109, R115, R117
YES
YES
NONO
NO
3. VIDEO NOISE, UNSYNCHRONOUS
20
