2) MultiSync V921-1 Different Parts List
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 BRACKET(PWB)ASSY 12000341 BRACKET(PWB,A) 1
2 BRACKET(PWB)ASSY 12000351 BRACKET(PWB,BL) 1
3 BRACKET(PWB)ASSY 12000361 BRACKET(PWB,BR) 1
4 BRACKET(PWB)ASSY 12000371 BRACKET(PWB,C) 1
5 BRACKET(PWB)ASSY 12000381 BRACKET(PWB,D) 1
6 BRACKET(PWB)ASSY 14000071 SCREW (PL-CPTS*3*8*15BF) 6
7 CABINET FRONT ASSY 10100981 CABINET FRONT 1
8 CABINET FRONT ASSY 11300501 PUSH BUTTON (CONTROL) 1
9 CABINET FRONT ASSY 11300511 PUSH BUTTON (SW) 1
10 CABINET FRONT ASSY 11600191 LENS 1
11 CABINET FRONT ASSY 13000011 COIL SPRING 1
12 PACKING ASSY 13201131 CARTON BOX V921(R) 1
13 PACKING ASSY 13400291 POLYON(T) 1
14 PACKING ASSY 13400301 POLYON(B) 1
15 PACKING ASSY 13700021 BAG POLYETHYLENE (270*370) 1
16 PACKING ASSY 13700031 BAG POLYETHYLENE (150*370) 1
17 PACKING ASSY 13700071 PE BAG (500*480*850 + WARNING) 1
18 PACKING ASSY 15500701 OWNERS MANUAL V721/V921(R Ver.) 1
19 PACKING ASSY 15700043 WARRANTY CARD (AUST) 1
20
REVOLVING STAND ASSY
11000361 REVOLVING STAND ASSY(B)
2nd TOOLING
OR
21
REVOLVING STAND ASSY
17000451 CUSHION SHEET(14.8*14.8*T4)
FOR 2nd BASE
OR
22
REVOLVING STAND ASSY
11000251 REVOLVING STAND (B) 1
23
REVOLVING STAND ASSY
11000261 REVOLVING STAND (T) 1
24
REVOLVING STAND ASSY
17000291 CUSHION SHEET 4
25 SET ASSY 80006241 WIRE GND 1015 18AWG L=160mm BLACK
BLACKET-CRT
1
26 SET ASSY 80001651
POWER CORD 3P 1.8M EUROPE NON-SHIELD COLOR SG8508(CTOA6)
CORD POWER
1
27 SET ASSY 80006691 CRT 19" LG M46QCG913X01(S) 6UD CRT 1
28 SET ASSY 80006231 WIRE GND 1015 18AWG L=150mm BLACK
CRT-CHASSIS
2
29 SET ASSY 80006661 DEGAUSSING COIL AS90 TCO-LG CRT
DEGAUSSING
1
30 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm FBT-CRT 1
31 SET ASSY 80006241 WIRE GND 1015 18AWG L=160mm BLACK FBT-CRT 1
32 SET ASSY 80011301 CRT GND WIRE MS95 GND WIRE 1
33 SET ASSY HA030010 EMI FILTER COIL 20*10*10 ROTATION 1
34 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm
SOCKET-CRT
1
35 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm
SOCKET-CRT
1
36 SET ASSY R0191207 TAPE BLACK L=75mmX3
0.015
37 SET ASSY 15200201 LABEL (EMC) (V500R) 1
38 SET ASSY 10100971 CABINET FRONT ASSY 1
39 SET ASSY 10100992 CABINET BACK 1
40 SET ASSY 11000331 REVOLVING STAND ASSY 1
41 SET ASSY 12000402 BRACKET(L) 1
42 SET ASSY 12000412 BRACKET(R) 1
43 SET ASSY 12000601 BRACKET(CABLE) 1
44 SET ASSY 12000441 BRACKET(PWB)ASSY 1
45 SET ASSY 12300181 PLATE,SHIELDING(VIDEO) 1
46 SET ASSY 15000542 NAME PLATE INSTRACTION V921 1
47 SET ASSY 15200031 LABEL (REV.) 1
48 SET ASSY 15200331 LABLE,SERIAL BARCODE 1
49 SET ASSY 15200681 LABEL TCO99(FOR CABINET) 1
50 SET ASSY 15200741 LABEL(RATED) 1
51 SET ASSY 15200791 LABEL (WAENING) 1
52 SET ASSY 17000301 CUSHION PIECE (BACK) 1
53
To Next Page
