4) AccuSync 90 Different Parts List
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 BRACKET(PWB)ASSY 12000341 BRACKET(PWB,A) 1
2 BRACKET(PWB)ASSY 12000351 BRACKET(PWB,BL) 1
3 BRACKET(PWB)ASSY 12000361 BRACKET(PWB,BR) 1
4 BRACKET(PWB)ASSY 12000371 BRACKET(PWB,C) 1
5 BRACKET(PWB)ASSY 12000381 BRACKET(PWB,D) 1
6 BRACKET(PWB)ASSY 14000071 SCREW (PL-CPTS*3*8*15BF) 6
7 CABINET FRONT ASSY 10100961 CABINET FRONT 1
8 CABINET FRONT ASSY 11300521 PUSH BUTTON (CONTROL) 1
9 CABINET FRONT ASSY 11300531 PUSH BUTTON (SW) 1
10 CABINET FRONT ASSY 11600191 LENS 1
11 CABINET FRONT ASSY 11700251 KEY COVER 1
12 CABINET FRONT ASSY 13000011 COIL SPRING 1
13 PACKING ASSY 13201091 CARTON BOX AS90(A)-1 1
14 PACKING ASSY 13400291 POLYON(T) 1
15 PACKING ASSY 13400301 POLYON(B) 1
16 PACKING ASSY 13700021 BAG POLYETHYLENE (270*370) 1
17 PACKING ASSY 13700031 BAG POLYETHYLENE (150*370) 1
18 PACKING ASSY 13700071 PE BAG (500*480*850 + WARNING) 1
19 PACKING ASSY 15500631 OWNERS MANUAL(AS50/AS70/AS90-1) 1
20 PACKING ASSY 15800051 SAFETY INSTRUCTION SHEET 1
21
REVOLVING STAND ASSY
11000361 REVOLVING STAND ASSY(B)
2nd TOOLING
OR
22
REVOLVING STAND ASSY
17000451 CUSHION SHEET(14.8*14.8*T4)
FOR 2nd BASE
OR
23
REVOLVING STAND ASSY
11000251 REVOLVING STAND (B) 1
24
REVOLVING STAND ASSY
11000261 REVOLVING STAND (T) 1
25
REVOLVING STAND ASSY
17000291 CUSHION SHEET 4
26 SET ASSY 80006241 WIRE GND 1015 18AWG L=160mm BLACK
BLACKET-CRT
1
27 SET ASSY 80001631
POWER CORD 3P 1.8M NON-SHIELD
¬ü³W
COLOR SG8508
CORD POWER
1
28 SET ASSY 80003541 CRT 19" SAMAUNG M46QCE261X112 CRT 1 S
29 SET ASSY 80006321 CRT 19" LG M46QCG913X01(u) CRT 1 L
30 SET ASSY 80006231 WIRE GND 1015 18AWG L=150mm BLACK
CRT-CHASSIS
2
31 SET ASSY 80006311 DEGAUSSING COIL AS90
DEGAUSSING
1
32 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm FBT-CRT 1
33 SET ASSY 80006241 WIRE GND 1015 18AWG L=160mm BLACK FBT-CRT 1
34 SET ASSY 80011301 CRT GND WIRE MS95 GND WIRE 1
35 SET ASSY HA030010 EMI FILTER COIL 20*10*10 ROTATION 1
36 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm
SOCKET-CRT
1
37 SET ASSY 80011321 WIRE BRAIDED 0.12/120C 180mm
SOCKET-CRT
1
38 SET ASSY R0191207 TAPE BLACK L=75mmX3
0.015
39 SET ASSY 10100812 CABINET BACK 1
40 SET ASSY 10100951 CABINET FRONT ASSY 1
41 SET ASSY 11000331 REVOLVING STAND ASSY 1
42 SET ASSY 12000601 BRACKET(CABLE) 1
43 SET ASSY 12000402 BRACKET(L) 1
44 SET ASSY 12000412 BRACKET(R) 1
45 SET ASSY 12000441 BRACKET(PWB)ASSY 1
46 SET ASSY 12300181 PLATE,SHIELDING(VIDEO) 1
47 SET ASSY 15000532 NAME PLATE INSTRUCTION 1
48 SET ASSY 15200031 LABEL (REV.) 1
49 SET ASSY 15200281 LABLE,SERIAL BARCODE 1
50 SET ASSY 15200491 LABEL(MANUFACTURE,NPG) 1
51 SET ASSY 15200541 LABLE WARNING (29KV) 1
52 SET ASSY 15200702 LABEL CRA AS90/AS90M 1
