5) AccuSync 90M Different Parts List
ASSY CODE PART NO DESCRIPTION LOCATION Q'TY ALT REMARK
1 AUDIO BASE ASSY 80006011 AUDIO SIGNAL CABLE CABLE 1
2 AUDIO BASE ASSY 80005891 WIRE UL1015AWG22 L150mm BLUE CN-AC1 1
3 AUDIO BASE ASSY 80005901 WIRE UL1015AWG22 L150mm BROWN CN-AC1 1
4 AUDIO BASE ASSY 80005871 WIRE UL1015AWG22 L250mm BLUE CN-AC2 1
5 AUDIO BASE ASSY 80005881 WIRE UL1015AWG22 L250mm BROWN CN-AC2 1
6 AUDIO BASE ASSY 80005941 WIRE UL1007AWG24 L100mm / UL TUBE CN-B 1
7 AUDIO BASE ASSY 80005911 WIRE UL1015AWG22 L100mm BLUE CN-T 1
8 AUDIO BASE ASSY 80005921 WIRE UL1015AWG22 L100mm BROWN CN-T 1
9 AUDIO BASE ASSY 80005931
WIRE UL1015AWG22 L100mm GREEN / YELLOW
CN-T 1
10 AUDIO BASE ASSY 80005971 UL TUBE L20mm CN-T 2
11 AUDIO BASE ASSY 80005991 AC INLET SK-015A INLET 1
12 AUDIO BASE ASSY 80006001 AC OUTLET SK-1008 OUTLET 1
13 AUDIO BASE ASSY 80005981 SPEAKER D(57-29)FL SP 2
14 AUDIO BASE ASSY 80005951 WIRE UL1007AWG24 L50mm ORANGE SPL 1
15 AUDIO BASE ASSY 80005961 WIRE UL1007AWG24 L50mm GRAY SPL 1
16 AUDIO BASE ASSY 80005941 WIRE UL1007AWG24 L100mm / UL TUBE SPR 1
17 AUDIO BASE ASSY 80005861 SW.REG ASR-16MSA SW.REG 1
18 AUDIO BASE ASSY 11000311 REVOLVING STAND(B)(AB) 1
19 AUDIO BASE ASSY 11000321 COVER STAND(AB) 1
20 AUDIO BASE ASSY 17000441 CUSSION SHEET(D20.8*d7*t5) 4
21 AUDIO BASE ASSY 11300561 PUSH BUTTON 1
22 AUDIO BASE ASSY 11300571 KNOB CONTROL 1
23 AUDIO BASE ASSY 13000071 COIL SPRING(D5*10.) 1
24 AUDIO BASE ASSY R0315A04 CABLE TIE L=100mm W=2.5mm 2
25 AUDIO BASE ASSY 14000031 SCREW(#2CBRITS*4*12*15BF) 6
26 AUDIO BASE ASSY 12000431 BRACKET (SP) 2
27 AUDIO BASE ASSY 15200771 LABEL(SERIAL NO.) 1
28 AUDIO BASE ASSY 15000471 NAME PLATE INSTRACTION(N9001) 1
29 AUDIO PCB ASSY 72000402 AUDIO PCB
AUDIO PCB
1
30 AUDIO PCB ASSY GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C11 1
31 AUDIO PCB ASSY GB210458 CERAMIC Y5V/T 0.1u/50V Z C12 1
32 AUDIO PCB ASSY GA347625 ELECT 85oC/T 47u/16V M C13 1
33 AUDIO PCB ASSY GA310725 ELECT 85oC/T 100u/16V M C14 1
34 AUDIO PCB ASSY GB210458 CERAMIC Y5V/T 0.1u/50V Z C15 1
35 AUDIO PCB ASSY GAA47725 ELECT 85oC/A 470u/16V M C16 1
36 AUDIO PCB ASSY GA310555 ELECT 85oC/T 1u/50V M C17 1
37 AUDIO PCB ASSY GB910358 CERAMIC Z5V(F)/T 0.01u/50V Z C21 1
38 AUDIO PCB ASSY GB210458 CERAMIC Y5V/T 0.1u/50V Z C22 1
39 AUDIO PCB ASSY GA347625 ELECT 85oC/T 47u/16V M C23 1
40 AUDIO PCB ASSY GA310725 ELECT 85oC/T 100u/16V M C24 1
41 AUDIO PCB ASSY GB210458 CERAMIC Y5V/T 0.1u/50V Z C25 1
42 AUDIO PCB ASSY GAA47725 ELECT 85oC/A 470u/16V M C26 1
43 AUDIO PCB ASSY GA310555 ELECT 85oC/T 1u/50V M C27 1
44 AUDIO PCB ASSY GAA47725 ELECT 85oC/A 470u/16V M C31 1
45 AUDIO PCB ASSY GA310725 ELECT 85oC/T 100u/16V M C32 1
46 AUDIO PCB ASSY 80006021 IC LA4227 IC1 1
47 AUDIO PCB ASSY 80004071 JK HSJ2000-01-010 JK1 1
48 AUDIO PCB ASSY 80006041 LED L-1154GD LED1 1
49 AUDIO PCB ASSY 80006051 LED HOLDER LED1 1
50 AUDIO PCB ASSY FA040103 CARBON 1/8W(T) 5% 10K R11 1
51 AUDIO PCB ASSY FA040103 CARBON 1/8W(T) 5% 10K R12 1
52 AUDIO PCB ASSY FA040102 CARBON 1/8W(T) 5% 1K R13 1
