EXAMPLES OF CONNECTIONS.
CAUTIONS ON CONNECTIONS:
• Unplug the projector and other equipment from the AC
supply before making connections.
• Make sure that the plug of the power cord is properly
connected to the power outlet. A loose connection may cause
hum or noise.
• Confirm your connection layout with the user’s manual
accompanying the equipment to be connected with the ISS-
6020/ISS-6020G Switcher.
NOTE: This projector does not have built-in speakers.
• Make sure that the STANDALONE mode is selected from the CONNECT CONDITION menu. Contact your dealer for the
information in detail.
When Used in Stand Alone Operation
Components with RGB and H/V SYNC
outputs such as a personal computer
External Control
VCR or Video disc player
VCR with S-Video outputs
ACAT OUT R(VIDEO) G(Y) B(C) H/HV V S-VIDEO VIDEO OPTION REMOTE1 REMOTE2
CUT IN
INPUT SELECT ENTERON/OFFINDICATOR
I
INPUT SELECT POWER
To Next Page
