NEC NP-PX800X Installation Guide

NEC Display Solutions of America, Inc.
PX700W/PX750U/PX800X Installation Guide
Desktop and Ceiling Mount Rev 1.0
www.necdisplay.com PX700W/PX750U/PX800X Page 4 of 12
Formulas: 4:10 Aspect Ratio (PX800X—XGA)
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for “W” in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2 and 3:
Projection Formulas: Definitions: 4:3 Screen Formulas
NP16FL: C = 0.822W – 1.866 W = Image Width W = H x 4/3
NP17ZL: C(Wide) = 1.358W – 2.094 ------ C(Tele) = 1.934W – 1.913 H = Image Height (size) H = W x 3/4
NP18ZL: C(Wide) = 1.828W – 2.681 ------ C(Tele) = 2.397W – 2.642 C = Throw distance Screen Diagonal = W x 5/4
NP19ZL: C(Wide) = 2.343W – 3.154 ------ C(Tele) = 3.883W – 3.118
NP20ZL: C(Wide) = 3.789W – 5.323 ------ C(Tele) = 5.689W – 5.299
NP21ZL: C(Wide) = 5.664W – 11.638 ------ C(Tele) = 8.834W – 11.535
Distance Chart for popular 4:3 Screens (XGA)
Rear Lens
NP16FL
Diagonal Width(W) Height (H) 0.76:1
inches inches inches inches
40 32 24 24.4 41.4 - 60.0 55.8 - 74.1 68.6 121.1 115.9 176.7 222.6 271.2
60 48 36 37.6 63.1 - 90.9 85.1 - 112.4 104.5 - 183.3 176.5 267.8 345.7 412.5
67 54 40.2 42.2 70.7 - 101.7 95.3 - 125.8 117.1 - 205.0 197.8 299.6 388.8 462.0
72 58 43.2 45.5 76.1 - 109.5 102.6 - 135.4 126.0 - 220.5 212.9 322.4 419.5 497.3
84 67 50.4 53.4 89.2 - 128.1 120.2 - 158.4 147.6 - 257.8 249.3 - 377.0 493.4 - 582.1
90 72 54 57.3 95.7 - 137.3 128.9 - 169.9 158.3 - 276.5 267.5 - 404.3 530.3 - 624.5
100 80 60 63.9 106.5 - 152.8 143.6 - 189.1 176.3 - 307.5 297.8 - 449.8 591.8 - 695.2
120 96 72 77.0 128.3 - 183.8 172.8 - 227.5 212.2 - 369.7 358.4 - 540.8 714.9 - 836.5
150 120 90 96.8 160.9 - 230.2 216.7 - 285.0 266.0 - 462.8 449.4 - 677.4 899.5 - 1048.5
180 144 108 116.5 193.5 - 276.6 260.6 - 342.5 319.8 - 556.0 540.3 - 813.9 1084.1 - 1260.6
210 168 126 136.2 226.1 - 323.0 304.4 - 400.1 373.7 - 649.2 631.2 - 950.5 1268.7 - 1472.6
240 192 144 156.0 258.6 - 369.4 348.3 - 457.6 427.5 - 742.4 722.2 - 1087.0 1453.3 - 1684.6
NP21ZL
5.30-8.30:1
i
nc
h
es
Zoom Lenses
i
nc
h
es
i
nc
h
es
1.29-1.79:1 1.73-2.27-1
i
nc
h
es
i
nc
h
es
Screen Size (16:10)
3.60-5.40:1
NP17ZL NP18ZL NP19ZL NP20ZL
2.22-3.67:1

NEC NP-PX800X Specifications

General

Brand	NEC
Model	NP-PX800X
Category	Projector
Language	English
