3.14 [ 030-15. OTHER ADJUST ]

Adjusts the various gains.

Command

03h 10h 00h 00h 05h <DATA01> - <DATA0 5> <CKS>

Data part

Item Description

DATA01

DATA02

DATA01 DATA02 Adjustment target

96h FFh LAMP ADJUST / LIGHT ADJUST

DATA03 Adjustment mode

00h Specify an absolute value

01h Specify a relative value

DATA04 Adjustment value (low-order 8 bits)

DATA05 Adjustment value (high-order 8 bits)
