NEC V332X - Page 43

36
English ...
Installation
Screen Size
(B)
(C)
D
(WIDE)
α
α
Diagonal (A) Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm inch mm inch mm degreedegree
240 6096 204 5169 127 3231 80 2025 315 8012 346 8788 16 409 14.2 13.0
270 6858 229 5816 143 3635 90 2278 355 9014 389 9887 18 460 14.2 13.0
300 7620 254 6462 159 4039 100 2531 394 10016 432 10985 20 512 14.2 13.0
* This table is for user’s reference only.
*The values in the tables are design values and may vary.
Projection Image Size from 40” to 300” (1.02 to 7.62 meters).
Model: NP-V302H
Screen Size
(B)
(C)
D
(WIDE)
α
α
Diagonal (A) Width Height Wide Tele Wide Tele
inch mm inch mm inch mm inch mm inch mm inch mm inch mm degreedegree
40 1016 35 886 20 498 13 331 52 1328 63 1594 3 82 14.0 11.7
60 1524 52 1328 29 747 20 496 78 1992 94 2391 5 123 14.0 11.7
70 1778 61 1550 34 872 23 579 92 2324 110 2789 6 143 14.0 11.7
80 2032 70 1771 39 996 26 662 105 2657 126 3188 6 164 14.0 11.7
90 2286 78 1992 44 1121 29 745 118 2989 141 3586 7 184 14.0 11.7
100 2540 87 2214 49 1245 33 827 131 3321 157 3985 8 205 14.0 11.7
120 3048 105 2657 59 1494 39 993 157 3985 188 4782 10 246 14.0 11.7
150 3810 131 3321 74 1868 49 1241 196 4981 235 5977 12 307 14.0 11.7
180 4572 157 3985 88 2241 59 1489 235 5977 282 7173 15 368 14.0 11.7
200 5080 174 4428 98 2491 65 1655 261 6641 314 7970 16 409 14.0 11.7
240 6096 209 5313 118 2989 78 1986 314 7970 377 9564 19 491 14.0 11.7
270 6858 235 5977 132 3362 88 2234 353 8966 424 10759 22 553 14.0 11.7
300 7620 261 6641 147 3736 98 2482 392 9962 471 11955 24 614 14.0 11.7
* This table is for user’s reference only.
*The values in the tables are design values and may vary.
