Appendices
Electrical NP-V302X NP-V302W NP-V332X NP-V332W NP-V302H
Inputs 1 x VGA and Y/Pb/Pr, 2 x
HDMI *4 (Standard HDMI
connector), 1 x VGA
Audio (Stereo mini jack), 1
x Composite Video (RCA
(yellow)), 2 x Composite
Audio (RCA for both left
and right)
1 x VGA and Y/Pb/Pr, 2 x HDMI *4
(Standard HDMI connector and one with
MHL function support), 1 x VGA Audio
(Stereo mini jack), 1 x Composite Video
(RCA (yellow)), 2 x Composite Audio
(RCA for both left and right)
Outputs 1 x VGA (D-sub female 15 pin connector) (Separate sync signal only), 1
x Audio (Stereo mini jack(green))
PC Control 1 x PC Control Port (D-Sub 9 Pin)
Wired LAN Port 1 x RJ-45 (10/100 BASE-T/100 BASE-TX)
Service Port Mini USB type B (for FW download)
Color Reproduction 1.07 billion colors simultaneously with 10-bit signal processing
Compatible
Signals *5
Analog VGA/SVGA/XGA/XGA+/SXGA/Quad-VGA/SXGA+/UXGA/
PowerBook G4/iMac DV (G3)/WSVGA/WXGA/WXGA+/WSXGA/
WUXGA/480i/480p/576i/576p/720p/1080i/1080p
HDMI VGA/SVGA/XGA/XGA+/SXGA/Quad-VGA/SXGA+/UXGA/
PowerBook G4/iMac DV (G3)/WSVGA/WXGA/WXGA+/WSXGA/
WUXGA/480i/480p/576i/576p/720p/1080i/1080p
Horizontal Resolution 540 TV lines: NTSC/NTSC4.43/PAL/PAL-M/PAL-N/PAL60
300 TV lines: SECAM
Scan Rate Hsync Frequency: 24kHz ~ 102kHz
Vsync Frequency: 48kHz ~ 120 Hz
Sync Compatibility Separate Sync
Built-in Speaker 8W
Power Requirement 100 - 240V AC 50/60Hz
Input Current 2.5-1.0 A 2.5-1.0 A 2.7-1.1 A 2.8-1.1 A 2.8-1.2A
Power Consumption (Typical value)
Eco Mode OFF 251W (*6) /
237W (*7)
249W (*6) /
237W (*7)
275W (*6) /
263W (*7)
277W (*6) /
263W (*7)
280W (*6) /
266W (*7)
Eco Mode 206W (*6) /
198W (*7)
205W (*6) /
194W (*7)
213W (*6) /
204W (*7)
215W (*6) /
204W (*7)
217W (*6) /
207W (*7)
Network Stand-by 1.6W (*6) /
1.8W (*7)
1.5W (*6) /
1.8W (*7)
1.6W (*6) /
1.8W (*7)
1.5W (*6) /
1.8W (*7)
1.6W (*6) /
1.8W (*7)
Normal Stand-by 0.22W (*6) /
0.37W (*7)
0.23W (*6) /
0.38W (*7)
0.23W (*6) /
0.35W (*7)
0.22W (*6) /
0.35W (*7)
0.22W (*6) /
0.35W (*7)
