32
English ...
Installation
Screen Size
(B)
(C)
D
(WIDE)
α
Diagonal
Width Height Wide Tele Wide
Tele
inch
mm
inch mm inch mm inch mm inch mm inch mm inch mm
degree degree
90 2286 72 1829 54 1372 35 891 140 3566 155 3932 8 206 14.0 12.8
100 2540 80 2032 60 1524 39 990 156 3962 172 4368 9 228 14.0 12.8
120 3048 96 2438 72 1829 47 1188 187 4754 206 5242 11 274 14.0 12.8
150 3810 120 3048 90 2286 58 1486 234 5943 258 6553 13 343 14.0 12.8
180 4572 144 3658 108 2743 70 1783 281 7131 310 7863 16 411 14.0 12.8
200 5080 160 4064 120 3048 78 1981 312 7923 344 8737 18 457 14.0 12.8
240 6096 192 4877 144 3658 94 2377 374 9508 413 10484 22 548 14.0 12.8
270 6858 216 5486 162 4115 105 2674 421 10697 464 11795 24 617 14.0 12.8
300 7620 240 6096 180 4572 117 2971 468 11885 516 13105 27 685 14.0 12.8
* This table is for user’s reference only.
* The values in the tables are design values and may vary.
