(2) VGA Analog - Extended Wide timing
Modes Resolution (dots)
V.Frequency
[Hz]
H.Frequency
[KHz]
HD 1280x720 60 44.8
WXGA 1280x768 60 47.78
WXGA 1280x768 75 60.29
WXGA 1280x768 85 68.63
WXGA 1280x800 60 49.6
WXGA 1366x768 60 47.71
WXGA+ 1440x900 60 55.9
WSXGA 1680x1050 60 65.3
Full HD 1920x1080 60 67.5
WUXGA 1920x1200 60 74.0
(3) VGA Analog - Component Signal
Modes Resolution (dots)
V.Frequency
[Hz]
H.Frequency
[KHz]
480i 720x480 59.94(29.97) 27
480p 720x480 59.94 31.47
576i 720x576 50(25) 27
576p 720x576 50 31.25
720p 1280x720 60 45
720p 1280x720 50 37.5
1080i 1920x1080 60(30) 33.75
1080i 1920x1080 50(25) 33.75
1080p 1920x1080 60 67.5
1080p 1920x1080 50 56.25
