Necta BRIO "Easy Serving Espresso" User Manual

TECHNICAL MANUAL “ Brio Easy serving Espresso“
Manual Brio ESE 2 / 17
NOTE
The above units are specific to this machine.
All functional units not mentioned are used also in other machines and are described as such in a separate
manual specific to the relevant range of machines.
View of Brio “ESE” with door open
Table of Contents
1
2
3
4
5
6
7
8
9
Layout
Electrical systems and board connections
Air-break / Boilers
Pumps and by-pass
Coffee brewer unit
Mixer Unit
Powder and water dose tables
Trouble-shooting
Wiring diagrams
Page
Pages
Page
Page
Pages
Page
Page
Pages
Page
3
4/5/6/7
8
9
10/11/12/13
14
14
15/16
17
Cup Dispenser
Sugar and stirrer
release devices
Brewing unit
Powder
containers for
instant drinks
Container for
used coffee
pods
Sugar container
Safety switch
Cu
p
release and
rotation unit
