Necta BRIO "Easy Serving Espresso" User Manual

TECHNICAL MANUAL “ Brio Easy serving Espresso“
Manual Brio ESE 6 / 17
RELAY CODE TABLE AND ACTUATIONS
RELAY
CODE
ACTUATION DESCRIPTION
K1
Three-way relief solenoid valve
K2
Three-way relief solenoid valve 2
K3
Instant drink solenoid valve 2
K4
Pump
K5
Coffee brewer motor
K6
Instant drink solenoid valve 2
K7
Pod strip (Serving) drive motor
K8
Mixer motor 1
K9
Doser device 3
K10
Doser device 2
K11
Doser device 1
K12
Sugar doser device
K13
Cup release motor
K14
Stirrer release motor
K15
Cup stacker shift motor
K16
Water inlet solenoid valve
K17
Mixer motor 2
