VP1007-200PM-00 ISO Reader I/O Manual version 0.4 / Page 11
Appendix A: Specifications
Specifications VP1007 (part no 9926542)
Dimensions 143 x 120 x 68 mm LxWxH (excluding mounting rail) Weight: ± 360 gr
Power Input voltage 25 VDC, +20% -20%
Minimal power consumption 300 mA with antenna switched on
Maximum power consumption 4,5 A
Protected against reverse connection power supply
Communication CAN, RS485 and RS232
Software Downloadable thru network
Inputs Reading inputs, analog (0-40V) and digital.
Suitable for NPN and PNP sensors.
Outputs Max. +0.4 / -1.7 Amp by current limiter, short-circuiting protected
I/O safe-guard when total I/O current > 4A
Antennas Different types possible
Detection distance Varies per antenna
Synchronisation Synchronization according to ISO 11785
Environment Temperature: Operating: -10 – 50 °C, Storage: -25 – 70 °C
Relative humidity: 10 – 93% non condensing
IP class IP 30. When installed in V-box IP 65 (cover and cables installed correctly!)
Cable specifications
Power
CAN-bus
Min. 1.5 mm
2
Min. 0.34 mm
2
twisted pair shielded
Antenna Coax RG58. Max. length depending on antenna type.
Outputs CE approved at cable length < 3m
Inputs CE approved at cable length < 3m
Synchronisation Twisted pair min. 0.34mm
2
shielded Total max. 500m
Always use a NEDAP power supply
The Nedap guarantee-regulations are only valid when is installed as indicated in this manual.
Install data cables at a safe distance from (high) powered cables
More information
For more detailed information contact your local Nedap supplier or check the internet site.
