1 Introduction Page 9
Stud welding unit operating manual Date: July 2021
ALPHA 850 07.2021 / EN Rev.: A
Accessories (options):
• Connecting cable (standard):
ALPHA 850 - workpiece:
1 Earthing cable H01N2-D (with 2 earthing clips):
Cable diameter: 35 mm
2
Minimum bending radius: 130mm
Length 5.0 m: Order No. 68-01-92
(others on request)
ALPHA 850 - sorter:
1 Cable set complete with welding cable and control cable:
Welding cable
Cable diameter: 50 mm
2
Length 5.0 m: Order No. 68-03-63
(others on request)
Control cable, 7-pin:
Cable diameter: 8 × 0.5 mm
2
Length 5.0 m: Order No. 68-04-82
(others on request)
• Connecting cable (extension):
ALPHA 850 - Gun NS 40:
1 Cable set complete with welding cable and control cable:
Welding cable diameter: 50 mm
2
Control cable diameter: 4 × 1.5 mm
2
Length 7.5 m: Order No. 67-01-16
Length 10.0 m: Order No. 67-03-29
