1.3 Specifications
CD WELDING UNIT MODEL
NCD+™ 1000T
NCD+™ 1600T
Input Voltage (V) / Current (A) / Frequency (Hz)
115 / 10 / 60
Capacitor Voltage (VDC) (Continuously Adjustable)
70 - 200
Stored Energy (Ws)
1080
1620
Capacitance (mF)
54
81
Weight
24 lb. (10.9 kg)
26 lb. (11.8 kg)
Maximum Stud Thread Diameter (Steel, Stainless)
1/4” (6.4 mm)
5/16” (8 mm)
Maximum Stud Thread Diameter (Aluminum)
#10 (M5)
1/4” (M6)
Weld Rate
(studs/min)
Vset
Studs/Minute
100
9
7
120
8
6
140
7
5
160
6
4
180
5
4
200
4
3
Dimensions (Length x W x H)
12.75” x 12” x 9”
(324 mm x 305 mm x 229 mm)
Power Cord
9 ft (2.75 m)
Idle Power (W)
40 or Less
Operating Temperature (°C)
-20 to + 40
Storage Temperature (°C)
-40 to + 60
Gun Connector
12-Pin Binder
Weld Connector
Dinse
Dual Ground
Yes
Compatible Guns
NCD+™ Contact, NCD+™ Auto-Gap
Process Monitor
Yes – Optional
Contact Safety Check
Yes
Chuck Saver™
Yes
Stud Expert™
Yes
Display
Graphic Color Display
