NCD+ 1000T & 1600T Manual | Welding Parameters
Part No. 729-110-038 Rev. 1.21 | May 2016 24 © 2014 Nelson Stud Welding, Inc. All Rights Reserved.
4.3 Weld Setting Recommendations
Weld Setting Change
Effect on Welds
Capacitance Increase
Hotter
Voltage Increase
Hotter
Spring Pressure Increase
Colder
Contact Mode-Plunge Increase
Colder
Gap Mode-Gap Increase
Colder
Stud Tip Length Increase
Hotter
