Nelson NCD+ 1600T User Manual

NCD+ 1000T & 1600T Manual | Parts List & Exploded View
Part No. 729-110-038 Rev. 1.21 | May 2016 26 © 2014 Nelson Stud Welding, Inc. All Rights Reserved.
52
8
524-005-315
SCREW, HHCS FLANGED, M5 x 10 SS
30
53
1
524-005-078
NUT, HEX, M10 SS
60
54
4
524-005-291
WASHER, FLAT, M5 SS
55
4
524-005-304
WASHER, LOCK, M5 SS
56
4
524-005-316
SCREW, HHCS, M5 x 30 SS
40
57
6
524-005-302
WASHER, FLAT, M3 SS
58
1.7'
727-029-218
EDGE TRIM, PLASTIC W/METAL CORE
59
4
524-005-336
SCREW, PHMS, M4 x 50 SS
20
60
6
524-005-303
WASHER, LOCK, M4 SS
61
1
714-033-000
GROMMET, RUBBER
63
2
524-005-272
NUT, KEPS, M3 SS
10
65
1
724-569-000
DECAL, GENERAL WARNING
66
2
524-005-276
WASHER, FLAT, M6 SS
67
2
524-005-343
SCREW, PHMS, M4 x 8 SS
20
68
2
524-005-287
WASHER, FLAT, M8 SS
69
1
750-614-239
BRACKET, TRANSFORMER BOTTOM
(70)
5
717-615-103
CABLE TIE, HARSH ENVIRONMENT
(71)
1
101-208-278
STUDS, CD
(72)
1
560-300-013
CARTON, INNER
(73)
1
560-300-012
CARTON, OUTER
(74)
1
560-200-004
PACKAGING, FOAM SET
(75)
1
723-247-206
HARNESS, JUMPER FOR VLTG. CONFIG.
(76)
1
723-247-207
CABLE, (+)DINSE TO SCR
(77)
1
723-247-201
HARNESS, PWR. BRD. TO CTRL. BOARD
(78)
1
723-247-204
HARNESS, SCR EXT. GATE AND
CATHODE
(79)
1
723-247-205
HARNESS, PWR. SW. TO CIRCUIT BRKR.
(80)
1
723-247-212
CABLE (-) DINSE TO (-) BUSS
(81)
1
750-614-246
KIT, ASSEMBLY
(82)
1
750-614-244
KIT, HARNESS
(83)
1
750-614-243
KIT, SHEETMETAL
(84)
1
750-614-242
KIT, DECAL
