Nelweld Operations and Service Manual
- 5 -
5.3
MAINTENANCE SCHEDULE 45
6.0
TROUBLESHOOTING ................................................................................................................................................. 46
6.1
SAFETY PRECAUTIONS 46
6.2
DIAGNOSTIC CODES – TROUBLESHOOTING GUIDE 47
6.3
MACHINE – TROUBLESHOOTING GUIDE 48
7.0
MISCELLANEOUS INFORMATION .........................................................................................................................52
7.1
TIMING DIAGRAMS 52
7.2
TIMING DIAGRAM DEFINITIONS 53
7.3
FUNCTION CODE DEFINITIONS 55
7.4
CONTROL FUSES 559
7.5
DECLARATION OF CONFORMITY 60
8.0
DIAGRAMS AND PARTS LISTS................................................................................................................................. 59
8.1
FRONT SECTION 59
8.2
BASE AND SIDE CABINET SECTION 61
8.3
TRANSFORMER AND TOP CABINET SECTION 63
8.4
REAR CABINET SECTION 65
8.5
WIRING DIAGRAM 67
Notes:
Only for EU countries
Do not dispose of Nelson stud welding units and system
components with household waste!
Nelson stud welding units and system c
devices
1
and therefore exclusively designed for
commercial use.
We expressly point out that Nelson stud welding units and
system components must neither be disposed of with
household waste nor at municipal collection points!
In accordance with the European 2002/96/EC directive on
waste electrical and electronic equipment
the scope of this directive’s translation into national
law, Nelson offers the collection and environmentally-
compatible disposal of its units and system
components against payment of a fee.
Please contact us!
