Nelson Nelweld 6000 - Function Code Definitions

Nelweld Operations and Service Manual
- 55 -
7.3 Function Code Definitions
Description
Default
Value
Minimum
Value
Maximum
Value
Units Zero state One state Comments
F1 Error Display E--- E001 E018
Scrolls through error codes of
active errors
F2 Weld Through Deck 0 0 1 disabled enabled
Only Nelweld 6000 can enable
this option
F3 Plunge Time 0.050 0.050 0.250 sec
Default changes to 0.180 if weld
through deck enabled.
F4 Pilot Arc Time 0.050 0.010 0.100 sec
F5 Prevent Welding if Error 0 0 1 disabled enabled
Disables output capability when
weld-related error occurs.
F6 Input Power Detection Scheme 0 0 1 autodetect generator
Generator or power grid
detection
F11 Lift Check Enable 1 0 1 disabled enabled
F12 Lift Check Delay Time 2000 500 9999 sec
F13 Lift Check Hold Time 2000 500 9999 sec
F14 Gas Valve Enable 0 0 1 disabled enabled
F15 Gas Valve Preflow Time 0.500 0 5.000 sec
F16 Gas Valve Postflow Time 0.500 0 5.000 sec
F21 Feed Signal Enable 0 0 1 disabled enabled
F22 Feed Signal Level 0 0 1 active low active high
F23 Feed Signal Style 0 0 1 contact loss after weld
F24 Feed Signal Pulse Width 0.010 0.010 0.500 sec
F25 Feed Signal Air Trigger Enable 1 0 1 disabled enabled
Stud feed on air trigger.
Overridden if F21 is disabled.
F26 Quick Retry Enable 0 0 1 disabled enabled
Truncates gun lift time on
misfire.
F31 User Weld Counter (millions) 0 0 999
Resettable user weld counter -
millions
F32 User Weld Counter (thousands) 0 0 999
Resettable user weld counter -
thousands
F33 User Weld Counter (hundreds) 0 0 999
Resettable user weld counter -
hundreds
F34 Total Weld Counter (millions) 0 0 999
Non-resettable total weld
counter - millions
F35 Total Weld Counter (thousands) 0 0 999
Non-resettable total weld
counter - thousands
F36 Total Weld Counter (hundreds) 0 0 999
Non-resettable total weld
counter - hundreds
F41 Chuck Stripper Enable 0 0 1 disabled enabled
F42 Chuck Stripper Delay Time 0.200 0.010 2.000 sec
F43 Chuck Stripper Hold Time 0.050 0.010 0.500 sec
F44 Reset to Factory Defaults FAC Reset all non-preset parameters
F45 Front Panel Lock Enable 0 0 1 disabled enabled
F46 Supervisor’s Lock Combination 1234 1111 6666 Password must be 4 digits.
F51 Model Number 4000 2000 6000
Read only - Nelweld model
number (2000-6000)
F52 Line Frequency 60.0 40.0 70.0
Read only - Updates every 5
sec.
F53 Software Version X.XX Read only
F54 Software Installation Month/Day mmdd
Month and day the software was
installed as mmdd
F55 Software Installation Year yyyy
Year software was installed as
yyyy
F56 Chuck Saver Enable 1 0 1 disabled enabled
Allows multiple weld attempts
without breaking contact
F61 Factory Use 750 0 1000
F62 Factory Use ABC ABC ACB
F63 Factory Use 1 1 2
F64 Factory Use 0 0 4000
F65 Factory Use 20 20 20 x
F66 Diagnostic Mode Enable 0 0 1 disabled enabled
Enable for troubleshooting weld
problems
