Nelson Nelweld 6000 - Page 66

Nelweld Operations and Service Manual
- 66 -
1 Gun
2 Gun
Cabinet rear panel, 3000/4000
1
1
750-601-203
Cabinet rear panel, 5000/6000
1
1
750-600-206
Plenum, small single fan, 3000
1
1
750-602-200
Plenum, large single fan, 4000
1
1
750-601-204
Plenum, dual fan, 5000/6000
1
1
750-600-207
A3
Plenum assembly hardware, nut M5 keps
7
7
524-005-204
A4
Plenum assembly hardware, washer 5mm flat
7
7
524-005-118
Fan, small, 3000
1
1
729-096-010
Fan, large, 4000
1
1
729-096-000
Fan small, 5000/6000
2
2
729-096-010
A6
Wiring harness, 5000/6000
1
1
723-241-021
Pilot arc resistor, 2 resistor assembly
1
0
705-001-007
Pilot arc resistor, 3 resistor assembly
0
1
705-001-006
A8
Ground braid for SCR Power PCB
1
2
723-241-012
A9
Grommet, push type
3
3
717-140-002
Fan mounting hardware, screw, 3000
4
4
524-001-273
Fan mounting hardware, screw, 4000
4
4
524-001-272
Fan mounting hardware, screw, 5000/6000
4
4
524-001-273
Fan mounting hardware, washer, 3000
4
4
524-002-123
Fan mounting hardware, washer, 4000
4
4
524-002-033
Fan mounting hardware, washer, 5000/6000
4
4
524-002-123
J1
Case rear panel mounting bolt
4
4
524-005-218
A10 A11
Label
Description
Quantity
Part Number
A1
A2
A5
A7
