10. SPECIFICATIONS *per IEEE1547A
MODEL BDM-600
INPUT(DC)
Max Recommended PV Power(Wp) 340 x 2
Max DC Open Circuit Voltage(Vdc) 60
Max DC Input Current (Adc) 12 x 2
MPPT Tracking Accuracy >99.5%
MPPT Tracking Range(Vdc) 22-55
OUTPUT(AC)
Peak AC Output Power(Wac) 550
Rated AC Output Power(Wac) 500
Nominal Power Grid Voltage(Vac) 240
Allowable Power Grid Voltage(Vac)
211-264 (Adjustable
*
)
Allowable Power Grid Frequency(Hz)
59.3-60.5(Adjustable
*
)
THD
<3% (at rated power)
Power Factor
>0.99 (at rated power)
SYSTEM
EFFICIENCY
CEC Eiency 95.5%
Night Time Tire Loss(W) 0.11
PROTECTION
FUNCTIONS
Over/Under Voltage Proon Yes
Over/Under Frequency Protecon Yes
An-Islanding Pro Yes
Over Current Pro Yes
Reverse DC Polarity Proon Yes
Overload Pro Yes
Ground Fault De Integrated
Pron Degree NEMA-6
Environment Temperature -40
℃
~+65
℃
Operang Temperature -40
℃
~ +85
℃
OTHER
PARAMETERS
Display
LED LIGHT
Communons POWERLINE
Dimension (D-W-H mm) 277*132*50
Weight(Kg) 2.9
