Netafim NETAJET 4G Installation Manual

NETAJET
™
4G INSTALLATION MANUAL 13
DESCRIPTION
Modes
• BP PL : Bypass system for pressurized-line water source; 5 dosing channels (see page 14)
• BP ST : Bypass system for storage-tank water source; 5 dosing channels (see page 16)
• High-flow : High-flow bypass system for pressurized-line water source; 5 dosing channels (see page 18)
• Octa - 8-channel : Bypass system for pressurized-line water source; 6-8 dosing channels (see page 20)
• IL PL : Inline system for pressurized-line water source; 5 dosing channels (see page 22)
• IL ST : Inline system for storage-tank water source; 5 dosing channels (see page 24)
Legend:
BP Bypass
IL Inline
PL Pressurized line
ST Storage tank
Main parts of the NetaJet™ 4G and its infrastructure
The list below presents the main parts of the NetaJet™ 4G and the parts of the infrastructure required for
the operation of the NetaJet™ 4G various modes.
1
Dosing channel + Venturi
2
Dual dosing channel + Venturis
3
Inlet pressure gauge
4
Outlet pressure gauge
5
Lower manifold pressure gauge
6
Main line pressure gauge
7
Sampling outlet
8
Controller
9
EC/pH transducer
10
Dosing booster switchbox
11
pH sensor
12
EC sensor
13
Dosing booster
14
Check valve
15
Pressure switch
16
Pressure sustaining valve (PSV)
17
Pressure reducing valve (PRV)
18
Air release valve
19
Mixing chamber
20
Compensation channel
21
Onboard main line pump
22
Upper manifold filter
23
Main line pump
24
Main line filter
25
Main line water meter
26
Main line
pressure sustaining valve (PSV)
27
Manual valve (isolation)
28
Irrigation valve
29
Fertilizer/acid filter
30
Manual valve (fertilizer)
31
Fertilizer/acid stock tank
Color code: Supplied (part of the NetaJet™ 4G) Not supplied (part of infrastructure).
