Detailed PoE Results
PoE Result Description
Requested
Class
Class selected in the PoE test
settings
Received Class
Class acknowledgment received
by the LR G2 from the switch
TruePower™
Power
Measured wattage with load
Unloaded
Voltage
Measured voltage without load
TruePower™
Voltage
Measured voltage with load
PSE Type
Switch's advertised Power
Sourcing Equipment (PSE) type.
Recognized types are 1 4,
LTPoE++, Cisco UPOE, and PoE
Injectors. PSEs supporting UPOE
are classified under Type 2. If the
type cannot be determined, 1/2
is displayed.
Spare Pair
Status of spare pair negotiation
for UPOE (true or false)
Negotiation
Negotiation type for UPOE and
Class 4 (UPOE or LLDP)
Positive
Positive PoE cable pair IDs
Negative
Negative PoE cable pair IDs
51
LinkRunner G2 Tests and Results
