4U rack space: A standard 19 in. (48.30 cm) rack to
fit 4U shelves of the following dimensions.
Depth: 38.25 in. (97.16 cm)
Width: 17.66 in. (44.86 cm)
Height: 6.87 in. (17.46 cm)
Max Weight: 250 lb (113 kg)
A supported browser for the management software:
• Google Chrome (version 47 and later)
• Microsoft Internet Explorer (version 11 and later)
• Microsoft Edge (EdgeHTML 12 and later)
• Mozilla Firefox (version 31 and later)
• Safari (version 9 and later)
Install the hardware
Learn how to install a E2860, E5760, or DE460 storage system in a two-post rack or a
NetApp system cabinet.
Before you begin
• Register your hardware at
mysupport.netapp.com.
• Prepare a flat, static-free work area.
• Obtain an ESD wristband and take anti-static precautions.
Read through all the instructions before proceeding with the steps below.
Steps
1. Unpack the hardware contents, and then inventory the contained hardware against the packing slip.
2. Install the rails.
If instructions were included with your rack-mounting hardware, refer to them to learn how to install the
rails. For additional rack-mounting instructions, see
Rack-mount hardware.
For square hole cabinets, you must first install the provided cage nuts to secure the front
and rear of the shelf with screws.
3
