6. Reestablish any SnapMirror or SnapVault configurations.
Step 5: Return the failed part to NetApp
Return the failed part to NetApp, as described in the RMA instructions shipped with the
kit. See the
Part Return & Replacements page for further information.
Replace an LED USB module - AFF A700 and FAS9000
You can replace an LED USB module without interrupting service.
The FAS9000 or AFF A700 LED USB module provides connectivity to console ports and system status.
Replacement of this module does not require tools.
Steps
1. Remove the old LED USB module:
a. With the bezel removed, locate the LED USB module at the front of the chassis, on the bottom left side.
b. Slide the latch to partially eject the module.
c. Pull the module out of the bay to disconnect it from the midplane. Do not leave the slot empty.
2. Install the new LED USB module:
648
