Press blue button
Rotate boot media up and remove from socket
a. Press the blue button at the end of the boot media until the lip on the boot media clears the blue button.
b. Rotate the boot media up and gently pull the boot media out of the socket.
3. Align the edges of the replacement boot media with the boot media socket, and then gently push it into the
socket.
4. Check the boot media to make sure that it is seated squarely and completely in the socket.
If necessary, remove the boot media and reseat it into the socket.
5. Lock the boot media in place:
a. Rotate the boot media down toward the motherboard.
b. Placing a finger at the end of the boot media by the blue button, push down on the boot media end to
engage the blue locking button.
c. While pushing down on the boot media, lift the blue locking button to lock the boot media in place.
6. Close the air duct.
21

NetApp FAS8300 Specifications

General

Controller	Dual
Maximum Drives	1440
Form Factor	4U
NVMe Flash Cache	Supported
Operating System	ONTAP
High Availability	Yes
Drive Types	SSD, HDD, NVMe
Connectivity	10GbE, 25GbE, 40GbE, 100GbE, FC
Protocols	NFS, CIFS, iSCSI, FC, FCoE
Processor	Intel Xeon
Data Reduction	Yes (compression, deduplication, compaction)
Flash Cache	Supported
