NetComm NF18ACV Setup Guide

NF18ACV NC2 FAQs – Parental Control Setup Guide
6 of 10
FQ01103 v. 1.1 March 2019
© NetComm Wireless 2019
Blocking Methods
Method 1 – Set Internet blackout periods
This Parental Control function allows you to cut off all Internet access for all devices listed in in the selected profile
on set days and times.
1 Navigate to PARENTAL CONTROL, under the profile you want to apply the restriction, click on Edit Rules to
set schedule time.
2 Go to the Selected Timeslots section and click and drag your mouse cursor to select Timeslots.
To select multiple
Timeslots at once and hold the Control (Ctrl) key down and click and drag in multiple
Timeslots.
3 To unselect any timeslots, select the timeslots, hold the
CTRL/CMD key down and press the left mouse
button twice.
4 When you are satisfied with your selection(s), click the
Apply Internet Blackout button.

NetComm NF18ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1600 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB port	-
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
Output current	2 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	28 mm
Width	216 mm
Height	174 mm
Weight	558 g
