NetComm NF18ACV Setup Guide

NF18ACV NC2 FAQs – Parental Control Setup Guide
10 of 10
FQ01103 v. 1.1 March 2019
© NetComm Wireless 2019
Method 3 – Set Permanent (Category) Blocking
The Permanent Blocking functionality ensures that when websites or URLs that you deem unsuitable are added to a
blocked list and that list is set to be permanently blocked for a profile, then any website on that list will not be able
to be seen by anyone in the selected profile.
The same Blocked list can be permanently blocked by multiple profiles.
1 To apply a
Block list to a profile, click Edit Rules on the Current Profile you want the block list rule to apply
to.
2 In the
Rules and Categories area select the previously defined Block lists, referred to here as Categories,
that you want to be restricted by this schedule
3 For each selected
Category, open its drop-down menu and select Permanent Blocking.
4 Click
Save to apply this Permanent Blocking rule or rules to all devices assigned to this profile.

NetComm NF18ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1600 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB port	-
RJ-11 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
Output current	2 A
Output voltage	12 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	28 mm
Width	216 mm
Height	174 mm
Weight	558 g
