Technical Specifications
The following table shows the technical specifications for the router.
Table 5. Router specifications
DescriptionFeature
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, UPnP, and SMBData and routing protocols
North America: 120V, 60 Hz, input
All regions: 12V @ 1.0A output
Power adapter
Dimensions: 185 x 136.5 x 46 mm (7.2 x 5.4 x 1.8 in.)Dimensions
Weight: 250 g (0.55 lbs)Weight
0° to 35°C (32º to 95ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15 Class BElectromagnetic emissions
Four RJ-45 ports supporting 10/100BASE-TLAN
One RJ-45 port supporting 10/100BASE-TWAN
Maximum WiFi signal rate complies with the IEEE 802.11 standard.
Note that the maximum wireless signal rate is derived from IEEE Standard
802.11 specifications. Actual throughput can vary. Network conditions
and environmental factors, including volume of network traffic, building
materials and construction, and network overhead, lower actual data
throughput rate.
WiFi
Auto-rate sensingRadio data rates
IEEE 802.11 b/g/n 2.4 GHz
IEEE 802.11 a/n/ac 5.0 GHz
Data encoding standards
Limited by the amount of WiFi network traffic generated by each node
(typically 50–70 nodes)
Maximum computers per
WiFi network
User Manual139Supplemental Information
AC1000 WiFi Router Model R6080
