Model DS108 Dual Speed Hub Installation Giude
10 or 100 Mbps Transmission with the Hub
Two Model DS108 hubs can be daisy-chained together at 100 Mbps to support more than eight
PCs. For larger networks, use a 10/100 Mbps switch such as the NETGEAR Model FS104 switch.
The illustrations show both a two-hub daisy-chain configuration and a network that incorporates
the NETGEAR Model FS104 switch.
Connect Hubs at 10/100 Mbps
Model DS108 hub
Model DS108 hub
Model DS108 hub
Model FS104
10/100 Mb/s
switch
PCs
PCs
PCs
Switched network with Model DS108 hubs
Two Model DS108 hubs daisy chained
Server
8243FA
