NETGEAR EX6400 User Manual

Get Started
13
AC1900 WiFi Mesh Extender Essentials Edition
The location that you choose must be within the range of your existing WiFi router
network.
5. Plug the extender into an electrical outlet and wait for the Power LED
to light green.
6. Use the Router Link LED
to help you choose a spot where the extender-to-router
connection is optimal.
7. If the Router Link LED does not light amber or green, plug the extender into an outlet closer
to the router and try again.
Keep moving the extender to outlets closer to the router until the Router Link LED lights
amber or green.
Connect Ethernet-Enabled Devices
After the extender is connected to your existing WiFi network, you can connect a device to
the extender using an Ethernet cable. Then that device can access your existing network
through the extender-to-router WiFi connection.
WiFi router
Extender
Blu-ray player
Figure 3. Ethernet connection to the extender

NETGEAR EX6400 Specifications

General

Power plug	-
Ethernet LAN	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WEP, WPA, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in power socket	No
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	1900 Mbit/s
Product color	White
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	81.4 mm
Width	161 mm
Height	44.5 mm
Weight	300 g
