NETGEAR FS728TPv2 Hardware Installation Guide

Chapter 2: Physical Description | 11
FS728TP Hardware Installation Guide
LED Designations
Port LEDs
The following table describes the RJ-45 and SFP port LED designations. There are two LEDs
for each RJ-45 port.
LED Designation
Link/Speed/ACT LED mode for
port 1 to 24:
• Per port:
- Solid Green — A valid 100 Mbps link is established.
- Blinking Green — Packets transmitting/ receiving is occurring at
100 Mbps.
- Blinking Yellow — A valid 10 Mbps link is established.
- Flashing Yellow — No link is established.
PoE LED mode for port 1 to 24: • Per port:
- Off — No PoE powered device (PD) is connected.
- Solid Green — The PoE powered device (PD) is connected and
the port is supplying power.
- Solid Yellow — Indicates one of the following failures caused the
device not delivering power to that port:
Port Speed/Link/ACT LED for SFP
ports (port 25 to 26):
• Off — No link
• Solid Green — A valid 1000 Mbps link is established.
• Blinking Green — Packets transmitting/receiving is occurring at
1000 Mbps.
• Solid Yellow — A valid 100 Mbps link is established.
• Blinking Yellow — Packets transmitting/receiving is occurring at
100 Mbps.
RJ-45 jacks with LEDs for the four
10/100/1000 copper ports (port 25
to 28):
• Right LED (Link/ACT LED):
- Off — No link is established
- Solid Green — A valid link is established.
- Blinking Green — Packets transmitting/receiving is occurring.
• Left LED (Speed LED):
- Off — Either 10 Mbps link is established or no link established.
- Solid Green — A valid 1000 Mbps link is established.
- Blinking Green — A valid 100 Mbps link is established.
Each SFP port has its own indication LED.
• Indicates one of the following failures caused the device not
delivering power to that port:
• PD power demand exceeds the available power
• PoE current exceeds PD's classification
• Out of proper voltage band (44 VDC–57 VDC for IEEE 802.3af)
