Set Up Virtual Private Networking With IPSec Connections
399
ProSAFE Dual WAN Gigabit WAN SSL VPN Firewall FVS336Gv3
6. Select VPN > IPSec VPN > Mode Config.
The Mode Config screen displays.
As an example, the screen shows two existing Mode Config records with the names
EMEA Sales and Americas Sales:
• For EMEA Sales, a first pool (172.16.100.1 through 172.16.100.99) and second pool
(172.16.200.1 through 172.16.200.99) are shown.
• For Americas Sales, a first pool (172.25.100.50 through 172.25.100.99), a second
pool (172.25.210.1 through 172.25.210.99), and a third pool (172.25.220.80 through
172.25.220.99) are shown.
7. Under the List of Mode Config Records table, click the Add button.
The Add Mode Config Record screen displays.
