NETGEAR GS110EMX User Manual

Set Up a Fixed IP Address for the Switch
By default, the switch receives an IP address from a DHCP server (or a router that
functions as a DHCP server) in your network. However, the DHCP server might not always
issue the same IP address to the switch. For easy access to the switch local browser
interface, you can set up a fixed (static) IP address on the switch. This allows you to
manage the switch anytime from a mobile device because the switch IP address remains
the same.
To change the IP address of the switch, you can connect to the switch by one of the
following methods:
•
Through a network connection. If the switch and your computer are connected to
the same network (which is the most likely situation), you can change the IP address
of the switch through a network connection (see Set Up a Fixed IP Address for the
Switch Through a Network Connection on page 21).
•
Through a direct connection. In the unlikely situation that the switch is not connected
to a network, or for some reason you cannot connect to the switch over a network
connection, you can change the IP address of the switch by using an Ethernet cable
and making a direct connection to the switch (see Set Up a Fixed IP Address for the
Switch by Connecting Directly to the Switch Off-Network on page 22).
Set Up a Fixed IP Address for the Switch Through a Network Connection
If the switch and your computer are connected to the same network (which is the most
the likely situation), you can change the IP address of the switch through a network
connection.
To disable the DHCP client of the switch and change the IP address of the switch
to a fixed IP address by using a network connection:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection.
2. Launch a web browser.
3.
In the address field of your web browser, enter the IP address of the switch.
The login page displays.
4. Enter the switch password.
The default password is password. The password is case-sensitive.
The Switch Information page displays.
5.
From the DHCP Mode menu, select Disable.
The IP address fields become available.
User Manual21Install and Access the Switch in
Your Network
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS110EMX

NETGEAR GS110EMX Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Voice VLAN, Tagged VLAN, Port-based VLAN
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
DHCP features	DHCP client
Queue scheduling algorithms	Weighted Round Robin (WRR)
Noise level	0 dB
Power connector	DC-in jack
Installed SFP modules quantity	0
Gigabit Ethernet (copper) ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	10
Jumbo frames	10240
Forwarding rate	41.664 Mpps
Latency (1 Gbps)	4 µs
Latency (10 Gbps)	3 µs
MAC address table	16000 entries
Packet buffer memory	0.128 MB
Latency (10-100 Mbps)	7 µs
Number of multicast groups filtered	128
Safety	UL/cUL Listed (UL 60950-1)/CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, SubpartB, Class B ICES-003:2016 Issue 6, Class B ANSI C63.4:2014 N 55032:2012 +AC:2013 / CISPR 32:2012 / AS/NZS CISPR 32:2013, Class B EN 55032:2015 +AC:2016 / CISPR 32:2015 +COR1:2016 / AS/NZS CISPR 32:2015, Class B EN 61000-3-2:2014 EN 61000-3-3:2013 EN 55024:2010 +A1:2015
Product color	Black
LED indicators	Link, Power, Speed
Number of fans	0 fan(s)
Housing material	Metal
Electromagnetic compatibility	Class B
Output current	2.5 A
Output voltage	12 V
Power consumption (max)	15.6 W
Power consumption (typical)	6.6 W
Heat dissipation	53.35 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Package depth	270 mm
Package width	164 mm
Package height	85 mm
Package weight	1340 g
Shipping (inner) case width	490 mm
Shipping (inner) case height	339 mm
Shipping (inner) case length	391 mm
Shipping (inner) case net weight	15460 g
Number of layers per pallet (air)	4 pc(s)
Number of cartons per pallet layer	6 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	102 mm
Width	236 mm
Height	27 mm
Weight	750 g
