NETGEAR GS308EPP User Manual

A login window opens.
3. Enter the device management password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The password is case-sensitive.
The HOME page displays.
The switch connections show in the upper left of the page.
View the status of a port
You can view the status of and details about a port.
To view the status of a port:
1.
Open a web browser from a computer that is connected to the same network as the
switch, or connected directly to the switch through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
A login window opens.
3. Enter the device management password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The password is case-sensitive.
The HOME page displays.
The switch connections show in the upper left of the page.
The PORT STATUS pane displays on the right or the bottom of the HOME page,
depending on the size of your browser window.
A port that is in use shows as UP. A port that is not in use shows as AVAILABLE.
4. To view details about a port, select the port.
The pane displays detailed information about the port.
If the QoS mode on the switch is port-based (the default setting), the Priority field
displays on the page. If the QoS mode is 802.1P/DSCP, the Priority field does not
display.
For information about setting rate limits for incoming and outgoing traffic, setting
the port priority (if the QoS mode on the switch is port-based), setting the port speed
(by default, the speed is set automatically), enabling flow control, and changing the
port name label, see Manage
individual port settings on page 26
User Manual79Maintain and Monitor the Switch
Gigabit Ethernet Smart Managed Plus Switches Series 3XXEP and 3XXEPP

NETGEAR GS308EPP Specifications

General

Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	1000 Mbit/s
Jumbo frames	9216
MAC address table	4000 entries
DHCP features	DHCP client
Certification	CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI
Product color	Black
LED indicators	Activity, Link, PoE, Power, System
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	27 mm
Weight	490 g
