NETGEAR GS724T - ProSafe Switch User Manual

Page 19 of 20
APPENDIX C: TECHNICAL SPECIFICATIONS
This appendix provides technical specifications for the NETGEAR GS724T Gigabit Smart Switch.
Network Protocol and Standards Compatibility
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000Base-X
IEEE 802.3x flow control
Management
IEEE 802.1Q Static VLAN (Up to 24 ranging from 2 to 4K)
Port-based VLAN (Up to 24)
IEEE 802.1p Class of Service (CoS)
Port-based QoS (options High/Normal/Low/ Lowest)
Port Trunking - Manual as per IEEE802.3ad Link Aggregation
IEEE 802.1D Spanning Tree Protocol
RFC 1157 SNMP v1
Interface
24 RJ-45 connectors for 10BASE-T, 100BASE-TX, and 1000BASE-T (Auto Uplink™ on all ports)
with 2 SFP GBIC module bays that share with 2 RJ-45 ports for fiber connectivity
LEDs
Per port (Gigabit): Link/Activity, Speed, FDX/HDX
Per device: Power
Performance Specifications
Forwarding modes: Store-and-forward
Bandwidth: 48 Gbps
Network latency: Less than 20 microseconds for 64-byte frames in store-and-forward mode for 100 Mbps to 100 Mbps transmission
Buffer memory: 256 KB embedded memory per unit
Address database size: 8,000 media access control (MAC) addresses per system
Mean Time Between Failure (MTBF): 115,221 hours (~ 13 years)
Power Supply
Power Consumption: 29 W maximum
100-240VAC/50-60 Hz universal input
Physical Specifications
Dimensions (H x W x D): 1.6 x 17.3 x 8.1 in. (43 x 440 x 205 mm)
Weight: 6.0 lbs. (2.7 kg)
Environmental Specifications
Operating temperature: 0 to 40°C (32 to 104°F)
Storage temperature: -20 to 70°C (-4 to 158°F)
Operating humidity: 90% maximum relative humidity, non-condensing
Storage humidity: 95% maximum relative humidity, non-condensing
Operating altitude: 3,000 m (10,000 ft) maximum
Storage altitude: 3,000 m (10,000 ft) maximum
Electromagnetic Emissions
CE mark, commercial
FCC Part 15 Class A
VCCI Class A
C-Tick
Electromagnetic Immunity
EN 55022 (CISPR 22), Class A
Safety
CE mark, commercial
UL listed (UL 1950) / cUL IEC950 / EN60950
CSA certified (CSA 22.2 #950)

NETGEAR GS724T - ProSafe Switch Specifications

General

Model	GS724T
Product Line	ProSafe
Form Factor	Rack-mountable
Switching Capacity	48 Gbps
VLAN Support	Yes
Power Supply	Internal
Device Type	Switch
Power over Ethernet (PoE)	No
MAC Address Table Size	8K entries
Routing Protocol	Static routing
Remote Management Protocol	HTTP, HTTPS
Features	VLAN, QoS, IGMP snooping, port mirroring
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Management	Managed
Weight	3.6 kg
