NETGEAR GS750E User Manual

To install the NETGEAR Switch Discovery Tool, discover the switch in your network,
and access the device UI of the switch:
1. Download the Switch Discovery Tool by visiting
netgear.com/support/product/netgear-switch-discovery-tool.aspx.
Depending on the computer that you are using, download either the Mac version
or the version for a 64-bit Windows-based computer.
2.
Temporarily disable the firewall, Internet security, antivirus programs, or all of these
on the computer that you use to configure the switch.
3.
Unzip the Switch Discovery Tool files, double-click the .exe or .dmg file (for example,
NETGEAR+Switch+Discovery+Tool+Setup+1.2.101.exe or
NetgearSDT-V1.2.101.dmg), and install the program on your computer.
The installation process places a NETGEAR Switch Discovery Tool icon on your
desktop.
4. Reenable the security services on your computer.
5. Power on the switch.
The DHCP server assigns the switch an IP address.
6. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection. The computer and the switch must be on
the same Layer 2 network.
7. Open the Switch Discovery Tool.
To open the program, double-click the NETGEAR Switch Discovery Tool icon on
your desktop.
The initial page displays a menu and a button.
8. From the Choose a connection menu, select the network connection that allows
the Switch Discovery Tool to access the switch.
9. Click the Start Searching button.
The Switch Discovery Tool displays a list of NETGEAR switches that it discovers on
the selected network.
For each switch, the tool displays the IP address.
10.
To access the device UI of the switch, click the ADMIN PAGE button.
The login page of the device UI opens.
11. Enter the switch password.
The default password is password. The password is case-sensitive.
The Switch Information page displays.
User Manual10Get Started
48-Port Gigabit Ethernet Plus Switch with 2 SFP Ports Model GS750E

NETGEAR GS750E Specifications

General

Switch type	Unmanaged
Stackable	-
Certification	VCCI Class A
Product color	Gray
Rack mounting	Yes
Housing material	Metal
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	48
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Virtual LAN features	Tagged VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	74.4 Mpps
Latency (1 Gbps)	4 µs
MAC address table	16000 entries
Packet buffer memory	1.5 MB
Mean time between failures (MTBF)	1031177 h
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	30 W
Heat dissipation	102.7 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	3250 g
