NETGEAR MA521 User Manual

This table describes the options available from the Configuration section:
Security
To prevent unauthorized wireless stations from accessing data transmitted over the network, the
Security section of the Configuration Utility offers secure data encryption, known as WEP
(Wired Equivalent Privacy), to better protect your data transmissions.
Configuration
Description
Network mode
Configurable between 802.11 Ad-hoc and Infrastructure modes. In
802.11 Ad-hoc mode, the wireless nodes form their own local
network where the end nodes communicate peer-to-peer without an
Access Point. In Infrastructure mode, the wireless searches all
available wireless channels to associate with an Access Point.
Channel
Specifies a channel only when using an Ad-hoc network mode.
Network Name (SSID)
Enter a 32-character (maximum) Service Set ID in this field; the
characters are case sensitive. When the wireless node is operating in
Ad-Hoc mode, this field operates as the Basic Service Set ID (BSSID).
All wireless nodes in the same network should use the same BSSID.
When in Infrastructure mode, this field defines the Extended Service
Set ID (ESSID). The ESSID assigned to the wireless node is required
to match the Access Point ESSID in order for them to communicate.
10

NETGEAR MA521 Specifications

Network Specifications

network speeds	1, 2, 5.5, 11 Mbps (auto rate capable)
modulation type	DBPSK, DQPSK, CCK
frequency band	2400 - 2497 MHz ISM band (channels 1 - 14)

Operating Environment

operating temperature	0 to 55° C (32 to 131° F)
storage temperature	-20 to 75° C (-4 to 167° F)
operating humidity	10-90% room humidity, noncondensing

Weight and Dimensions

dimensions	100 x 54 x 5 mm (3.93 x 2.13 x 0.2 in.)
weight	37 g (1.3 oz)
