To display Access Points around the working environment, select the Re-Scan button. In
addition to showing the MAC Address of each Access Point, you can also view the Channel,
Signal, Security, and Network Modes.
Click
OK to continue, or select another tab.
Statistics Section
The Statistics section of the Configuration Utility dialog box indicates the real-time Transmit and
Receive packets performance in graph form and also displays the performance statistics in figures.
Click OK to continue or select another tab.
This table describes the options available from the Statistics section:
Statistics
Description
Transmit/Receive
Performance
Displays the maximum and current Tx/Rx (Kbits/sec) performance statistics.
Transmit/Receive
Statistics
Monitors the Tx/Rx of the Kbits or packet statistics.
15
