Table 5. Technical specifications
SpecificationFeature
•
Input: 110–120V, 47–60 Hz
•
Output: 12 VDC, 1.5 A
Power adapter
•
Dimensions: (W X D X H) 6.8 x 3.7 x 8.2 in. (172 x 94 x 208 mm)
•
Weight: 1.09 lb (495 g)
Physical specifications
•
Operating temperature: 32° to 104°F (0° to 40°C)
•
Operating humidity: 90% maximum relative humidity, noncondensing
Environmental
•
Local: one 2.5 Gbps RJ-45 Gigabit Ethernet port
•
Aggregate: Two aggregated 1 Gigabit RJ-45 Ethernet ports
•
Internet: Coaxial cable connector DOCSIS 3.1; backward-compatible
with DOCSIS 3.0
Interface
•
2 OFDM and 32 SC-QAM bonded downstream
•
2 OFDMA and 8 SC-QAM bonded upstream
Channels
•
CableLabs certified for U.S. cable internet services.
•
FCC/UL
Certifications
User Manual28Supplemental Information
Nighthawk CM3000 2.5 Gbps Cable Modem
