NETGEAR Nighthawk EX7000 User Manual

Overview
7
AC1900 WiFi Range Extender
Unpack Your Extender
Your box contains the following items:
Extender
Stand
Antennas (3)
Power adapter
Rubber feet (4)
Top Panel LEDs and Front Panel USB Port
Use the LEDs during installation to find the best location for the extender or to monitor the
extender performance. The following figure shows the extender in an upright position, with
the stand attached. (For information about attaching the stand, see Attach the Stand on
page 9.)
2.4 GHz Link Rate LED
5 GHz Link Rate LED
Device to Extender LED
LAN LEDs (1 through 5)
USB LED
USB 3.0 port
NETGEAR Logo LED
Figure 1. LEDs and USB port

NETGEAR Nighthawk EX7000 Specifications

General

WiFi Technology	802.11ac
Number of Ethernet Ports	5
USB Ports	1 x USB 3.0
Antenna	3 external antennas
Processor	Dual-core 1GHz
WiFi Performance	AC1900
WiFi Band	2.4GHz and 5GHz
Ethernet Port Configuration	10/100/1000Mbps Gigabit Ethernet
Security	WPA/WPA2-PSK
