NETGEAR Nighthawk R6700 Installation

2
Install Your Router
Make sure that your Internet service is active before you install
your router.
¾ To install your router:
1. Remove the antenna caps.
Remove the antenna caps from the antenna posts on the
router.
2. Attach the antennas.
a. Align the antennas with the antenna posts on the router.
b. Attach the antennas on the threaded antenna posts.
c. Position the antennas for the best WiFi performance.
NETGEAR recommends that the center antenna be vertical
and that you aim the others outward at 45-degree angles,
as shown.
Antenna posts

NETGEAR Nighthawk R6700 Specifications

General

WiFi Speed	AC1750 (450 + 1300 Mbps)
USB Ports	1 x USB 3.0
Antenna	3 external antennas
Beamforming	Yes
Wireless Standard	802.11a/b/g/n/ac
Operating Temperature	32°F to 104°F (0°C to 40°C)
WiFi Technology	802.11ac
Ethernet Ports	4 x Gigabit Ethernet
Frequency Band	2.4 GHz and 5 GHz
Memory	128 MB Flash, 256 MB RAM
Security	WPA2-PSK
Dimensions	11.22 x 7.26 x 1.97 inches
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Processor	1GHz Dual Core Processor
