NETGEAR Nighthawk X4S D7800

To Next Page

To Previous Page

Enable FTP Access Within Your Network

File Transfer Protocol (FTP) lets you download (receive) and upload (send) large files faster.

For information about using FTP to access a storage device over the Internet, see Manage

Dynamic DNS and Access Storage Devices Through the Internet on page 167.

Note

To enable FTP access within your network:

1. Launch a web browser from a computer or WiFi device that is connected to the network.

2. Enter http://www.routerlogin.net.

A login window opens.

3. Enter the modem router user name and password.

The user name is admin.The default password is password.The user name and password are case-sensitive.

The BASIC Home page displays.

4. Select ADVANCED > ReadySHARE > Advanced Settings.

The previous figure shows two USB devices attached to the modem router.

Share a Storage Device

157

Nighthawk X4S AC2600 WiFi VDSL/ADSL Modem Router Model D7800
