Use VPN to Access Your Network

You can use OpenVPN software to remotely access your modem router using virtual private networking (VPN).This

chapter explains how to set up and use VPN access.

The chapter includes the following sections:

• Set Up a VPN Connection on page 258

• Use a VPN Tunnel on a Windows Computer on page 262

• Use VPN to Access the Modem Router’s USB Device and Media From a Windows Computer on page 264

• Use VPN to Access Your Internet Service at Home on page 264

257
